Feature: |
1. Pilot operated diaphragm structure,nylon reinforced. |
|
2. Double filtration to protect solenoid core. |
|
|
3. Water proof sealing coil. |
|
|
4. Optional internal or external loop,individual switch. |
|
|
5. Y shape to reduce water head lose and increase the flow. |
|
|
Medium: |
Water |
|
Temp： |
Water Temp ≤53*C, Surrounding Temp ≤80*C |
|
Application: |
One of the most widely used valves in agriculture and landscaping irrigation systemjike large area of lawn, stadium,agriculture,industrial dust and water treatment. |
|
Pressure: |
0.1-1 .OMPa |
|
Flow: |
201BM ≤60M3/h,251BM ≤65M3/H |
|
201BM ≤60M3/h,251BM ≤65M3/H |
|
|
Port size: |
2"BSP,2.5"BSP,3"BSP,4"Flange |
|
Port thread: |
Female G ,Flange |
|
Orifice: |
DN50 DN65 DN80 DN100 |
|
Voltage: |
AC220V/AC110V/AC24V,50/60Hz |
|
DC24V/DC12V/DC9V |
|
|
DC Latching |
|
|
Material: |
Body---------------------reinforced nylon |
|
Sealring------------------ NBR |
|
|
The movable iron core-stainless steel 430F |
|
|
The static iron core------stainless steel430F |
|
|
Springs ---------------- SUS304 |
|
|
Shading coil-------------red copper |
